MM-500

Cardioid Instrument Microphone

FEATURES & SPECIFICATION

RELATED PRODUCTS & ACCESSORIES

PRODUCT SUPPORT

Cardioid

Cardioid

Condenser

Condenser

3_Pin_XLR

3-Pin XLR

mm-500_1
mm-500_2
mm-500_3
mm-500_4
mm-500_1
mm-500_2
mm-500_3
mm-500_4
  • FEATURES & SPECIFICATION

  • RELATED PRODUCTS & ACCESSORIES

  • PRODUCT SUPPORT

  • FEATURES

    • Cardioid polar pattern balances focused pickup with natural tone, minimizing ambient interference and feedback.
    • Wide frequency response and high dynamic range preserve full sonic detail.
    • High-sensitivity capsule ideal for stage vocals, instrument miking, and live music production.
    • Rugged metal construction with precision protective design withstands demanding performance environments.

    SPECIFICATION

    Model

    MM-500

    Name

    Cardioid Instrument Microphone

    Polar Pattern

    Cardioid

    Capsule Type

    Condenser

    Frequency Response

    50 Hz – 20 kHz @ 94 dB SPL

    Sensitivity

    -43 dBV/Pa @ 1 kHz

    Residual Noise

    < 17 dBA SPL

    S/N Ratio

    > 78 dB @ 94 dB SPL

    Max SPL

    149 dB SPL

    Dynamic Range

    132 dB

    Output Impedance

    200 Ω

    Output Jack

    3-Pin XLR

    Power Supply

    +12 – 48V phantom power, 2 mA

    Housing & Construction

    Aluminum alloy

    Dimensions

    23 × 180 mm (Ø × L)

    Weight

    Approx. 130 g

    RELATED PRODUCTS

  • All (2)

  • Wireless Systems (2)

  • ta-80_s

    TA-80

    UHF Digital Plug-on Transmitter

    ta-58_s

    TA-58

    5 GHz Digital Plug-on Transmitter

    DOWNLOADS

  • USER GUIDE

  • SPEC SHEET

  • TITLE
    FILES
    SIZE
    DOWNLOAD
    MM Series
    MM-300 / MM-500 Cardioid High Sensitivity Recording Microphone
    1.04 MB
    MM-500
    Cardioid Instrument Microphone (Ver.2024)
    243.13 KB
