MTM-58 | 5 GHz Digital Interlinking Transmitter Module | MIPRO

MTM-58

5 GHz Digital Interlinking Transmitter Module

FEATURES & SPECIFICATION

RELATED PRODUCTS & ACCESSORIES

PRODUCT SUPPORT

Digital

ISM

5.8 GHz

LCD

  • FEATURES & SPECIFICATION

  • RELATED PRODUCTS & ACCESSORIES

  • PRODUCT SUPPORT

  • FEATURES

    • Operates on the ISM 5 GHz band, wirelessly transmitting audio to active speakers with matching receiver modules, expanding the coverage of portable PA systems.
    • Provides 12 preset channels with an LCD display for easy and intuitive control.
    • Incorporates a phase-locked loop (PLL) system to minimize interference and deliver reliable transmission quality.
    • Modular design enables direct installation in MIPRO portable PA systems for convenient setup and servicing.

    SPECIFICATION

    Model

    MTM-58

    Name

    5 GHz Digital Interlinking Transmitter Module

    Frequency Range

    ISM 5.8 GHz

    Channels

    Preset 12 channels

    Display

    LCD

    RF Power Output

    20 mW

    Compatible Models

    MIPRO MA-505, MA-708, MA-808, MA-727, MA-828 PLUS, MA-929 PLUS

    Dimensions

    75 × 35 × 165 mm (W × H × D)

    Weight

    Approx. 78 g

    ACCESSORIES

  • All (1)

  • Receiver Modules for Portable PA (1)

  • MRM-58

    5 GHz Digital Receiver Module

    DOWNLOADS

  • USER GUIDE

  • SPEC SHEET

  • TITLE
    FILES
    SIZE
    DOWNLOAD
    Interlinking Transmitters
    MTM-24 / MTM-58 / MTM-91 / MT-91 (Ver.2023)
    2.03 MB
    MTM-58
    5 GHz Digital Interlinking Transmitter Module (Ver.2024)
    167.45 KB
