MA-101ACT

Wall-Mounted Wireless Megaphone

PRODUCT INQUIRY

FEATURES & SPECIFICATION

RELATED PRODUCTS & ACCESSORIES

PRODUCT SUPPORT

analog

Analog

Bluetooth

Bluetooth

ACT_Sync

ACT Sync

ma-101act_1
ma-101act_2
ma-101act_3
ma-101act_1
ma-101act_2
ma-101act_3

  • FEATURES & SPECIFICATION

  • RELATED PRODUCTS & ACCESSORIES

  • PRODUCT SUPPORT

    •

    FEATURES

    • Wall-mount design with compact size, ideal for classrooms, meeting rooms, and small gatherings.
    • High-efficiency Class-D amplifier powers a 5-inch full-range speaker, delivering clear and powerful sound.
    • Built-in UHF receiver module supports 97 channels with a reception range of over 60 meters, enabling quick pairing and reliable interference-free performance.
    • Pairs with the dedicated MT-101ACT transmitter for remote power and volume control, supporting lavalier and headworn microphones.
    • Supports Bluetooth playback and LINE IN / LINE OUT connections for both wired and wireless audio sources.
    • Expandable with the MA-101EXP passive speaker for wider sound coverage.
    • Includes AC switching power supply for reliable and stable long-term operation.

    SPECIFICATION

    Model

    MA-101ACT

    Name

    Wall-Mounted Wireless Megaphone

    Max SPL

    104 dB SPL

    Speaker System

    5" full-range

    Output Power

    50 W RMS, 85 W Peak

    Frequency Response

    125 Hz – 17 kHz

    Amplifier

    Class D

    Built-in Features

    Supports remote control from MT-101ACT transmitter

    Audio Inputs

    LINE IN (6.3 mm)

    Audio Outputs

    LINE OUT (6.3 mm), EXT SP. (Input Terminals 4–16 Ω)

    Receiver Module

    1 × UHF module

    Player Module

    Built-in Bluetooth module

    Power Supply

    AC 100 – 240 V switching power supply

    Accessories

    MS-11 Wall Mount Bracket (optional)

    Dimensions

    190 × 275 × 150 mm (W × H × D)

    Weight

    Approx. 2.2 kg (battery included)

    ACCESSORIES

  • All (2)

  • Extension Speakers (1)

  • Stands & Mounts (1)

    •
    ma-101exp_s

    MA-101EXP

    Passive Extension Speaker

    ms-11_s

    MS-11

    Wall Mount Bracket

    DOWNLOADS

  • SPEC SHEET

  • USER GUIDE

    •
    TITLE
    FILES
    SIZE
    DOWNLOAD
    MA-101ACT
    Wall-mounted Wireless Megaphone (Ver.2023)
    221.57 KB
    Wall-Mounted PA
    MA-101ACT / MT-101ACT Wireless IR Remote Control PA System (Ver.2022)
    5.21 MB
