MA-707

Portable Wireless PA System

FEATURES & SPECIFICATION

RELATED PRODUCTS & ACCESSORIES

PRODUCT SUPPORT

UHF、ISM

UHF

UHF、ISM

ISM

Handle

Handle

Li-ion_Battery

Li-ion

Li-ion_Battery

Lead-acid

CD_Player

CD Player

USB

USB

ma-707exp_1_en
ma-707_2
ma-707exp_1_en
ma-707_2
  • FEATURES & SPECIFICATION

  • RELATED PRODUCTS & ACCESSORIES

  • PRODUCT SUPPORT

  • FEATURES

    • High-efficiency Class-AB amplifier drives a full-range speaker, delivering natural and bright sound, ideal for teaching, tours, and small to medium-sized events.
    • Modular design supports receiver and player modules, with external source and wired microphone inputs.
    • Receiver module offers multiple frequency band options and can be expanded to up to 2 sets for basic wireless microphone needs.
    • Optional player modules include CD and USB players for diverse music playback.
    • External speaker output allows connection to the MA-707EXP passive speaker for extended coverage.
    • Built-in retractable handle, wheels, and microphone storage compartment for easy transport, plus tripod mount for flexible setup.
    • Powered by built-in AC supply and rechargeable battery, ensuring long-lasting operation.

    SPECIFICATION

    Model

    MA-707

    Name

    Portable Wireless PA System

    Max SPL

    107 dB SPL

    Speaker System

    8" full-range

    Output Power

    100 W RMS, 170 W peak

    Frequency Response

    70 Hz – 14 kHz

    Amplifier

    Class AB

    Audio Processing

    Tone control

    Built-in Features

    AC power button

    Audio Inputs

    MIC IN (XLR & 6.3 mm), LINE IN (6.3 mm)

    Audio Outputs

    LINE OUT (6.3 mm), EXT SP. (6.3 mm)

    Receiver Module

    UHF / 2.4 GHz / 5 GHz, up to 2 (optional)

    Transmitter Module

    N/A

    Player Module

    CD/USB player (optional)

    Power Supply

    AC 100 – 240 V or DC 24 – 32 V

    Battery Type

    Built-in two Lead-acid battery packs (MB-70)

    Battery Indicator

    Single LED indicator for power and charging status

    Standby Time

    Up to 8 hours

    Accessories

    SC-707 dust cover, MS-70 tripod stand (optional)

    Dimensions

    325 × 518 × 258 mm (W × H × D)

    Weight

    Approx. 12.3 kg (battery included)

    ACCESSORIES

  • All (7)

  • Receiver Modules for Portable PA (1)

  • Playback Modules for Portable PA (1)

  • Extension Speakers (1)

  • Rechargeable Batteries (2)

  • Stands & Mounts (1)

  • Carrying Bags & Dust Covers (1)

  • mrm-24_s

    MRM-24

    2.4 GHz Digital Receiver Module

    cdm-2p_s

    CDM-2P

    CD/USB Playback Module

    ma-707exp_s_en

    MA-707EXP

    Passive Extension Speaker

    mb-70_s

    MB-70

    Rechargeable Lead-Acid Battery

    mb-80_s

    MB-80

    Li-ion Battery Case

    ms-70_s

    MS-70

    Tripod Speaker Stand

    sc-707_s

    SC-707

    Dust Cover

    DOWNLOADS

  • USER GUIDE

  • SPEC SHEET

  • DOC

  • TITLE
    FILES
    SIZE
    DOWNLOAD
    MA-707
    Portable Wireless PA System (Ver.2019)
    1.21 MB
    MA-707
    Portable Wireless PA System (Ver.2022)
    4.35 MB
    MA-707
    Portable Wireless PA System (Ver.2024)
    307.4 KB
    MA-707
    Portable Wireless PA System
    370.84 KB
