MJ-53

Condenser Microphone Adapter

PRODUCT INQUIRY

DETAILS

Adapter that converts MIPRO 4-pin mini XLR condenser microphones to standard XLR inputs, supporting 12–48 V phantom power. Delivers high S/N ratio, wide dynamic range, and stable audio performance. Features a full-metal housing and belt clip for professional use.

Adapter that converts MIPRO 4-pin mini XLR condenser microphones to standard XLR inputs, supporting 12–48 V phantom power. Delivers high S/N ratio, wide dynamic range, and stable audio performance. Features a full-metal housing and belt clip for professional use.

FEATURES & SPECIFICATION

PRODUCT SUPPORT

mj-53_1
mj-53_2
mj-53_3
mj-53_4
mj-53_1
mj-53_2
mj-53_3
mj-53_4

  • FEATURES & SPECIFICATION

  • PRODUCT SUPPORT

    •

    FEATURES

    • Converts MIPRO 4-pin Mini XLR condenser microphones to standard XLR inputs.
    • Supports 12 – 48 V phantom power supply.
    • Incorporates an electronically balanced amplifier circuit with approximately 200 Ω output, delivering high signal-to-noise ratio and wide dynamic range.
    • Provides a broad frequency response of 50 Hz – 20 kHz, ensuring stable and clear long-distance transmission.
    • Durable full-metal housing with belt clip for convenient professional use.

    SPECIFICATION

    Model

    MJ-53

    Name

    Condenser Microphone Adapter

    Frequency Response

    50 Hz – 20 kHz

    Output Impedance

    200 Ω (Balanced)

    Max Output Voltage

    2.52 V @ 1 kHz, THD 1%

    Dynamic Range

    120 dBA

    Input Jack

    MIPRO 4-pin Mini XLR

    Output Jack

    XLR

    Power

    12 – 48 V phantom power. Current Drain: 2.0 mA

    Dimensions

    19 × 90 mm (Ø × L)

    Weight

    Approx. 67 g

    DOWNLOADS

  • SPEC SHEET

    •
    TITLE
    FILES
    SIZE
    DOWNLOAD
    MJ-53
    Condenser Microphone Adapter (Ver.2024)
    162.83 KB
