MRM-58 | 5 GHz Digital Receiver Module | MIPRO

Products
Accessories
Receiver Modules for Portable PA
MRM-58
mrm-58_1
mrm-58_1

MRM-58

5 GHz Digital Receiver Module

PRODUCT INQUIRY

FEATURES & SPECIFICATION

RELATED PRODUCTS & ACCESSORIES

PRODUCT SUPPORT

Digital

Digital

rx-mode

True Diversity

UHF、ISM

ISM

Frequency_Range

5.8 GHz

Bandwidth

125 MHz

LED

LED

ACT_Sync

ACT Sync

mrm-58_1
mrm-58_1

  • FEATURES & SPECIFICATION

  • RELATED PRODUCTS & ACCESSORIES

  • PRODUCT SUPPORT

    •

    FEATURES

    • Operates on the ISM 5.8 GHz band with 12 preset channels, supporting 8 selectable IDs plus 1 special ID per channel, providing greater bandwidth and reduced interference.
    • Includes auto-scan and ACT synchronization functions for quick and intuitive frequency setup.
    • Employs true diversity reception technology to ensure highly stable wireless audio transmission.
    • LED indicators clearly show channel, RF and AF signal strength.
    • Modular design allows direct installation in MIPRO portable PA systems for efficient setup and servicing.

    SPECIFICATION

    Model

    MRM-58

    Name

    5 GHz Digital Receiver Module

    Frequency Range

    ISM 5.8 GHz

    Channels

    12 preset channels with 8 selectable IDs and one specific ID

    Display

    LED numeric channel, RF indicator and AF levels

    Channel Setting

    Manually set up the desired channel or scan for an open channel

    Frequency Synchronization

    ACT sync

    Receiving Mode

    True diversity

    S/N Ratio

    > 113 dBA

    Frequency Response

    20 Hz – 20 kHz

    Compatible Models

    MIPRO MA Series

    Dimensions

    75 × 35 × 147 mm (W × H × D)

    Weight

    Approx. 80 g

    RELATED PRODUCTS

  • All (2)

  • Wireless Systems (2)

    • act-580h_s

    ACT-580H

    5 GHz Digital Handheld Transmitter

    COMPARE

    act-580t_s

    ACT-580T

    5 GHz Digital Bodypack Transmitter

    COMPARE

    ACCESSORIES

  • All (3)

  • Transmitters for PA Systems (2)

  • Transmitter Modules for Portable PA (1)

    •
    mtm-58_s

    MTM-58

    5 GHz Digital Interlinking Transmitter Module

    act-58h_s

    ACT-58H

    5 GHz Digital Handheld Transmitter

    act-58t_s

    ACT-58T

    5 GHz Digital Bodypack Transmitter

    DOWNLOADS

  • SPEC SHEET

  • USER GUIDE

    •
    TITLE
    FILES
    SIZE
    DOWNLOAD
    MRM-58
    5 GHz Digital Receiver Module (Ver.2024)
    170.06 KB
    Receiver Modules
    MRM-24 / MRM-58 Digital Wireless Receiver Module (Ver.2021)
    2.32 MB
    Receiver Modules
    MRM-24 / MRM-58 Digital Wireless Receiver Module
    2.9 MB
