MM-90 | Supercardioid Vocal Microphone | MIPRO

MM-90

Supercardioid Vocal Microphone

FEATURES & SPECIFICATION

RELATED PRODUCTS & ACCESSORIES

PRODUCT SUPPORT

Supercardioid

Condenser

3-Pin XLR

  • FEATURES & SPECIFICATION

  • RELATED PRODUCTS & ACCESSORIES

  • PRODUCT SUPPORT

  • FEATURES

    • Supercardioid polar pattern offers greater isolation and reduces feedback risk.
    • High sensitivity and wide frequency response deliver detailed, penetrating vocals.
    • Features the MIPRO MU-90 interchangeable capsule for flexible maintenance and extended service life.
    • Multi-layer metal grille and zinc-alloy body provide durability and pop protection.
    • Professional-grade condenser wired microphone ideal for large stage performances and demanding live environments.

    SPECIFICATION

    Model

    MM-90

    Name

    Supercardioid Vocal Microphone

    Polar Pattern

    Supercardioid

    Capsule Type

    Condenser

    Frequency Response

    50 Hz – 18 kHz @ 94 dB SPL

    Sensitivity

    -47 dBV/Pa @ 1 kHz

    Residual Noise

    < 17 dBA SPL

    S/N Ratio

    > 77 dB @ 94 dB SPL

    Max SPL

    149 dB SPL

    Dynamic Range

    132 dB

    Output Impedance

    200 Ω

    Output Jack

    3-Pin XLR

    Power Supply

    +12 – 48V phantom power, 2 mA

    Housing & Construction

    Zinc-alloy body, featuring a replaceable capsule module with multi-layer metal grille.

    Dimensions

    51 × 200 mm (Ø × L)

    Weight

    Approx. 410 g

    ACCESSORIES

  • All (5)

  • Handheld Mic Capsules Modules (2)

  • Stands & Mounts (2)

  • Mic Color ID Accessories (1)

  • MU-90

    Supercardioid Condenser Microphone Capsule Module

    MU-70

    Cardioid Condenser Microphone Capsule Module

    SW-20

    Foam Windscreen

    MD-20

    Microphone Holder

    MS-20

    Tabletop Microphone Stand

    DOWNLOADS

  • USER GUIDE

  • SPEC SHEET

  • TITLE
    FILES
    SIZE
    DOWNLOAD
    MM Series
    MM-90 / MM-80 / MM-70 / MM-59 / MM-39 / MM-107 / MM-590 Wired Microphones (Ver.2019)
    3.08 MB
    MM Series
    MM-90 / MM-80 / MM-70 / MM-59 / MM-39 / MM-107 / MM-590 Wired Microphones (Ver.2021)
    2.66 MB
    MM-90
    Supercardioid Vocal Microphone (Ver.2024)
    254.49 KB
