TA-80

UHF Digital Plug-on Transmitter

PRODUCT INQUIRY

FEATURES & SPECIFICATION

RELATED PRODUCTS & ACCESSORIES

PRODUCT SUPPORT

Digital

Digital

UHF、ISM

UHF

Bandwidth

72 MHz

VFD

LCD

ACT_Sync

ACT Sync

Li-ion_Battery

Li-ion

IF

iF Design Award

ta-80_1
ta-80_2
ta-80_3
ta-80_4
ta-80_1
ta-80_2
ta-80_3
ta-80_4

  • FEATURES & SPECIFICATION

  • RELATED PRODUCTS & ACCESSORIES

  • PRODUCT SUPPORT

    •

    FEATURES

    • Full aluminum alloy housing provides superior durability and excellent RF shielding for reduced interference.
    • Digital transmission technology ensures high audio quality, low latency, and strong anti-interference performance, ideal for professional stage and studio applications.
    • Color LCD screen displays channel, battery, and signal status with intuitive operation.
    • XLR audio input compatible with most professional dynamic and condenser microphones.
    • Supports 12 V or 48 V phantom power to drive a wide range of condenser microphones.
    • Selectable RF power output of 10 / 50 mW allows flexible adjustment to match different environments.
    • Equipped with a replaceable 18500 lithium battery offering 5–8 hours of use, chargeable via MP-8T charging dock or external charger.

    SPECIFICATION

    Model

    TA-80

    Name

    UHF Digital Plug-on Transmitter

    Frequency Range

    UHF 480 – 934 MHz (country dependent)

    RF Power Output

    10 mW / 50 mW switchable (country dependent)

    Audio Control

    AF Gain, Low Cut, AF Limiter and Input Polarity

    Audio Input

    XLR female

    Max Input

    6 dBV (2 Vrms) @ 0 dB

    Phantom Power

    +12 V / +48 V at 10 mA max.

    Gain Control

    -18 dB to +30 dB, in 6 dB steps

    Control Interface

    ACT sync sensor, setting buttons and mute button

    Display

    Backlit LCD

    Power Supply

    One 18500 Li-ion battery

    Battery Charging

    MP-8T charging dock

    Dimensions

    44 × 114 × 39 mm (W × H × D)

    Weight

    Approx. 180 g
