Product Name : ISM Digital Plug-on Transmitter

*The product images and specifications shown on our website may differ from the actual products due to different versions.


  • Digital

  • ISM Band

  • 125 MHz

  • LCD Display

  • ACT™ Channel Synchronization

  • Li-ion
  • Operates in the ISM band to avoid the wireless interference signals.
  • The TA-58 features a flat and wide frequency response, ultra-low T.H.D. and noise floor, and fast transient response. It solves the problems of tangling microphone cables and defects of analog transmission. Thus, it is an ideal plug-on transmitter to reproduce the natural sound of any premium wired microphone.
  • A balanced XLR input jack for any condenser microphone to plug on. It supplies 48V, up to 10 mA phantom power for condenser microphone, and can be switched off for the dynamic microphones.
  • A built-in high-capacity lithium-ion battery enables up to 8 hours of use per charge. The TA-58 can be recharged via a USB Type-C socket. It is fast and easy to replace the battery with a foolproof design.
  • The fiber reinforced plastic housing has a built-in high efficiency transmitting antenna and a green backlit LCD displaying operation parameters.
Product Introduction
ModelTA-58
Name ISM Digital Wireless Plug-on Transmitter
Carrier-Frequency Range ISM 5.8 GHz (5,725~5,850 MHz)
Bandwidth 125 MHz
RF Output Power 20 mW (country dependent)
Gain Setting 0 dB
AF Input Level 2V max.
Phantom Power 48 V at 10 mA max.
Battery Type ICR 18500 lithium-ion battery
Charger USB Type-C
Dimensions 40 × 117 × 38 mm (W×H×D)
Weight Approx. 120 g
Note Refer to the actual product in the event of product discrepancy.

Download

Spec Sheet
TA-58 ISM Digital Plug-on Transmitter (Ver.2021) 0.18M | 2021/08/24
User Guide
TA-58 ISM Digital Plug-on Transmitter 2.00M | 2022/02/11
